| Model | SDL-60000-1/1 |
| Voltage & Frequency | 3p 380V @ 50Hz |
| Working current of the whole machine | 105.0A |
| Mechanical and electrical power | 59.0kW |
| App lication environment | 0℃＜Environment temperature＜45℃ , Relative humidity＜95% |
| Tempe. control accuracy | ±1℃ |
| Cooling capacity | 150kW |
| Refrigerant | R410A |
| Rated flow of water pump | 32m³/h |
| Rated head of water pump | 72m |
| Pump power | 11kW |
| Tank volume | 435L |
| nozzle interface | G1-1/2* φ45mm Pagoda hose connector*2 |
| Weighing power (P) | 60P |
| Size and weight of the machine | 2315mm*1440mm*1835mm（L*W*H），866kg |
| Packing size and weight | 2360mm*1530mm*1910mm（L*W*H），986kg |
| Functional characteristics | Efficiency & Environmental protection ； Flow & Over temperature alarm ；Thermal protection of compressor ；Air circuit-breaker |
| Unique advantage | Compact and small |
